LATHE:
SAMRAT:- HEAVY DUTY
Hari industries offers various types of lathe including heavy duty lathe machine. They are designed to create objects that have symmetry about an axis of rotation. These lathes are used for accurately machining comparatively hard materials.
Heavy Duty Lathe Machine Features
Our Heavy duty lathe machine is the perfect machining equipment for handling hard materials and it is a space saving workshop equipment.
We have created this equipment considering the smart aspects in technology to offer consumers with the best machining experience.
It also stays precise, fast, reliable and consistent.
The Product provision allows for accuracy in shaping metals and other types of work materials.
It keeps the work material from slipping off from the machining platform.
It offers comparatively speedy performance apart from precise mechanism.
Machining aspects are excellent as it is vibration free and requires lesser time and man power for operating and maintenance.
Special Features
Bed
- bed is graded alloy casting, all parts are manufactured in our foundry. High tensile strength cast 20 to 25 GRADE IRON.
- Rigid construction of bed for taking maximum loads.bed type 2v &2 Flat.
- Perfect gap bed machine insuring the real works.
- Hardened&Ground bed ways
General
- Graduations dial for tail stock &apron wheel movement.
- Metric system micro collar for all screw and nut.
- Tailstock sleeve is tang shank type of Heavy Drilling.
- Easy inter changeable parts.
Head Stock
- Head stock body is of latest specially design.
- Induction hardened and ground spindle of special alloy steel.All cen¬trifugal running parts are well balanced.
- Back Gears Teeth are Helix Angle
Apron
- Apron are totally enclosed oil bath system.
- Lever type arrangement for automatic feeds.
- T-slot on carriage for mounting special features.
Gear Box
- Gear box arrangement for real time savings equipment.
- Quick change gear box provides changes of feeds& threads.
| Model:SD-315 | Model:SD-390 | |
| Height of Center | 315mm. | 390mm. |
| Swing Over Slide | 428mm | 570mm. |
| Swing Over Bed | 630mm | 780mm. |
| Swing in Gap | 880mm | 1050mm. |
| Spindle Hole | 80mm | 80mm. |
| Spindle Nose | 6 T.P.I. | 6 T.P.I. |
| Spindle Speed No.8 | 30 To 550 RPM. | 27 To 353 RPM. |
| Cross Slide Size | 200*585mm | 200*585mm |
| Top Slide Travel | 140mm. | 220mm. |
| Engilsh Range | 2 T.P.I. To 56 T.P.I.No.36 | 1 T.P.I. To 28 T.P.I.No.32 |
| Metric Range | 0.05 mm. To 14 mm.No.35. | 1 mm. To 28 mm.No.32. |
| Lead Screw | ∅38 mm.-4 T.P.I. | ∅44 mm.-4 T.P.I. |
| Tail Stock Spindle | ∅71 mm. | ∅76 mm. |
| Tail Stock Sleeve | MT-4 | MT-5 |
| Tail Stock Ram Travel | 140mm. | 240mm. |
| Power Required | 5H.P.- 1440 RPM. | 5H.P.- 1440 RPM. |
| Bed of Width | 335mm | 390mm. |
| Bed Lenght (feet) Addimt Between Center |
1000mm.(7'-0") 1600mm.(9'-0") 1900mm.(10'-0") 2500mm.(12'-0") |
950mm.(7'-0") 1550mm.(9'-0") 1900mm.(10'-0") 2500mm.(12'-0"). |
| Space Required for 7'-0 W X L X H" | 1400mm*2550mm*1350mm | 1500mm*2550mm*1400mm |
